TAB e.module H10.2
The TAB e.module H10.2 is an advanced high-voltage battery module designed for modern Battery Energy Storage Systems (BESS). Developed and manufactured at TAB’s lithium-ion Gigafactory, which features one of the most advanced battery module manufacturing plants in the European Union with an annual production capacity of 1 GWh, the H10.2 combines European engineering excellence with cutting-edge energy storage technology.
Featuring a modular design concept, flexible scalability, and easy installation, it provides the ideal foundation for commercial and industrial energy storage applications. Built with safe and reliable Lithium Iron Phosphate (LFP) battery technology, the TAB e.module H10.2 delivers high performance, long service life, and exceptional operational reliability. As a key component of high-voltage energy storage systems, it supports renewable energy integration, self-consumption optimization, energy cost reduction, and backup power, helping customers achieve greater energy efficiency, energy independence, and sustainability goals.
ADVANTAGES
• Good thermal stability
• Long cycle life
• High power rating
• Safe
• LFP (lithium iron phosphate) cells enable highest safety
• Can be used for applications ranging from 48V up to 1000V
• Flexible paralleling to adapt to different project sizes
• Adaptable precharge circuit
• Compatible with any inverter and EMS brand, due to adaptable voltage and CAN/Modbus communications
• Designed and manufactured in the EU
• Grade A cell quality only
• Laser welding
• Integrated CCU
• AI quality checks
SPECIFICATION
| Basic Parameters | H10.2 |
| Nominal Voltage (Vdc) | 51.2 |
| Nominal Capacity (kWh) | 10240 |
| Depth Of Discharge (%) | 97 |
| Discharge Voltage (Vdc) | 44.8 |
| Charge Voltage (Vdc) | 56.8 |
| Charge/Discharge Current (A) | 140 |
| Communication Port | CAN, RS485 |
| Dimension (WxDxH, mm) | 391x1015x165 |
| Weight (kg) | 110 |
| Configuration (max. in 1 battery string) | 18 |
| Cooling Type | Air ventilation |
| Working Temperature (°C) | 0 ~ 60 (Charge) -20 ~ 60 (Disharge) |
| Storage Temperature (°C) | -30 ~ 45 (up to 1 Month) -20 ~ 35 (up to 1 Months)* |
| Humidity (%) | 0 ~ 95 (RH)** |
| Altitude (m) | ≤3000 |
| IP Rating | IP20 |
| Certification | IEC62619/CE/UN38.3, IEC63056, IEC61000-6-2, IEC61000-6-3 |
